Choice one or two sawhead configuration, servo motor fast saw movement and positioning accuracy

Micro-computer provides 100 settings of cutting dimensions capacity to meet flexible production demands, independently mounted control desk provides convenient operation.

Major functions screen displayed, combined with touch screen for maximum operational convenience, in addition foot switch or joystick control for blade movement control.

Electric rise and fall of ruggedly constructed pressure mechanism, choice of air loaded feed roller, individually adjustable.

• Spheroidal cast iron feed carpet, choice of replacable pads, variable feed 5 – 40M/min via frequency inverter controller.
• Digitally controlled lubricator to ensure oil film between chain and rails with low level interlock.
• Infeed – 3 rows of anti-kick back fingers
• Outfeed – powered fluted roller ensures smooth discharge of heavy/moist timber
• Hydraulic –guide lock spindle
• Laser line – accurate positioning of cut, reduces material waste.

Optional

3 type of driven roller infeed systems

1. Manual (details on request)
2. Semi auto (details on request)
3. Optimization  (details on request)
